Locks and strike boxes

PL 55 * Glass Fitting manual locking device fitting with round bolt

GEZE Glass Fitting PL 55 Floor lock, without cylinder, with round bolts
  • Elegant cover caps made of polished or brushed stainless steel
  • Problem-free adjustment to glass thicknesses of 10 – 12 mm
Contact us

Application Areas

  • For full-glass doors
  • For glass thicknesses 10 and 12 mm
  • For single-action and double-action doors
  • For internal and external systems
  • Suitable for single and double leaf swing doors

Technical data

PL 55
Dimensions 102 x 32 x 96 mm
Width 32 mm
Length 102 mm
Height 96 mm
Glass thickness (min.) 10 mm
Glass thickness (max.) 12 mm
Type of installation Glass installation
